ESP8266 NodeMcu Lua WIFI Board V3.0 CH340

৳ 480.00

The Development Kit based on ESP8266, integrates GPIO, PWM, IIC, 1-Wire and ADC all in one board. Power your development in the fastest way combine with NodeMCU Firmware! V3 version has CP340 USB-TTL instead, larger current support, slim board can put on breadboard.

Description

Features

  • NodeMCU is a Wi-Fi card designed to be used in IoT projects. It is based on an ESP8266 circuit and all its pins are available. In addition, a voltage regulator has been added, as well as a USB programming port. You can program with LUA or through the Arduino IDE
  • Its use is very widespread so there is a whole community and documentation that allows you to easily connect to the outside through Wifi
  • Because it uses a CH340 USB converter, the operating system usually installs it automatically, although depending on the case, you may need to install the specific driver.

Specifications

  • Processor: ESP8266 @ 80MHz (3.3 V) (ESP-12E)
  • 4MB of FLASH memory (32 MBit)
  • RESET button
  • External power input VIN (20 V max)
  • WiFi 802.11 b/g/n
  • Integrated 3.3 V regulator (500 mA)
  • USB-Serial CH340G / CH340G converter
  • Auto-reset function
  • 9 GPIO pins with I2C and SPI
  • 1 Analog input (1.0 V max)

Additional information

Dimensions 49 × 24.5 × 13 cm
